3W~24W Plastic Housing DOB Recessed Panel Light

Plastic Housing DOB Recessed Panel Light
Round Type:
JX-PL-RD-2.5″: 3W, Size:Ø97.5*H:24.5mm, cut-out size: Ø73mm
JX-PL-RD-3.5″: 6W, Size:Ø117.2*H:24.5mm, cut-out size: Ø91.5mm
JX-PL-RD-4.0″: 9W, Size:Ø145*H:25.2mm, cut-out size: Ø112mm
JX-PL-RD-6.0″: 12W, Size:Ø170*H:25.5mm, cut-out size: Ø138mm
JX-PL-RD-8.0″: 18W, Size:Ø225*H:28.5mm, cut-out size: Ø190mm
JX-PL-RD-10″: 24W, Size:Ø298*H:29.5mm, cut-out size: Ø258mm
Square Type:
JX-PL-SQ-4.0″: 9W, Size:145*145*H32mm, cut-out size: 115*115mm
JX-PL-SQ-6.0″: 12W, Size:176*176*H32mm, cut-out size: 145*145mm
JX-PL-SQ-8.0″: 18W, Size:223*223*H32mm, cut-out size: 190*190mm
JX-PL-SQ-10″: 24W, Size:298*298*H32mm, cut-out size: 258*258mm
Input Voltage: AC165~265V or AC90~265v
